Numericals on Parallel Plate Capacitor with Dielectric Slab between Plates
Class-12 Nootan ISC Physics Ch-4 Capacitors and Dielectrics.
Que-6. The area of each plate of a parallel-plate capacitor is 100 cm² and the distance between them is 0.05 cm. When it is filled with a dielectric, its capacitance becomes 3.54 x 10^-10 F. Find the dielectric constant.
Ans-6 Capacitance of capacitor with dielectric
C = kε0A/d
=> k = Cd/ε0A
= 3.54 x 10^-10 x 0.05 x 10^-2 / 8.85 x 10^-12 x 100 x 10^-4
= 3.54 x 5 / 8.85
= 2
Que-7. How much area of paper will be required to construct a parallel-plate capacitor of 0.004 µF, if the dielectric constant of the paper be 2.5 and its thickness be 0.025 mm?
Ans-7 C = kε0A/d
A = Cd/kε0
=> 0.004 x 10^-6 x 0.025 x 10^-3 / 2.5 x 8.85 x 10^-12
=> 100 x 10^-12 x 10^-3 / 2.5 x 8.85 x 10^-12
=> 4.52 x 10^-3 m
Que-8. We have a glass slab (K = 7) 4.0 mm thick, a mica foil (K = 6) 0.20 mm thick and an amber plate (K = 2) 2.0 cm thick. Which one be placed between the plates of a parallel-plate capacitor to obtain maximum capacitance?
Ans-8 C = kε0A/d = (k/d) ε0A
=> C ∝ k/d
for mica foil k/d = 6/(0.2 x 10^-3) = 3 x 10^4 (max)
∴ Mica foil is better
Que-9. The potential difference between the plates of a parallel- plate capacitor is 200 V. The area of each plate is 100 cm² and the distance between them is 1 mm. If the medium between them is air, then calculate the charge taken by the capacitor. If there is a medium of dielectric constant 2.5 between the plates, then what will be the potential difference for the same charge?
Ans-9 V = 200 V A = 100 x 10^-4 m^2
d = 1 x 10^-3 m
Q = CV = ε0A/d x V
=> 8.85 x 100 x 10^-4 x 200 / 1 x 10^-3
=> 1.76 x 10^-8 C
Potential with dielectric constant
= 200/2.5 = 80 V (V’ = V/k)
Que-10. A paper is placed between two plates of copper, area of each 100 cm². The thickness of the paper is 0.005 cm and its dielectric constant is 2.5. If the paper can bear an electric field of 5 x 10^5 V/cm, then calculate the maximum voltage up to which the capacitor can be charged. How much charge will be stored on the capacitor?
Ans-10 E = V/d => V = E.d
E = 5 x 10^5 V/cm = 5 x 10^5 x (10^-2) m^-1
=> 5 x 10^7 volt/m
∴ V = 5 x 10^7 x 0.005 x 10^-2
=> 2500 V
again charge Q = CV
=> kε0A/d x V = ε0A.E
=> 2.5 x 8.85 x 10^-12 x 100 x 10^-4 x 5 x 10^7
=> 1.1 x 10^-5 C
Que-11. When a 20 V battery is connected to an air-capacitor, a charge of 30 µC is obtained on the capacitor. When oil is filled between the plates of the capacitor, then a charge of 75 µC is obtained. Calculate (i) the dielectric constant of the oil, (ii) the energy contained in the oil-capacitor.
Ans-11 Charge in capacitor with dielectric
=> k.charge in air capacitor
=> 75 µC = k x 30 µC
=> k = 75/30 = 2.5
again energy = 1/2 CV^2 = 1/2 (CV).V = 1/2 q.V
=> 1/2 x 75 x 10^-6 x 20
=> 7.5 x 10^-4 J
Que-12. (a) A parallel-plate air capacitor has a plate area of 6 x 10^-3 m² and a plate separation of 3 mm. A PD of 100 V is established between its plates by a battery. After disconnecting the battery, the space between the plates is filled by a 3 mm thick mica sheet of dielectric constant K = 6. Find (i) the new PD between the plates, (ii) the final capacitance and (iii) the final charge on the capacitor.
Ans-12 (a) When di electric slab is inserted after removing battery then
(i) V = V0/k = 100/6 volt
(ii) C = KC0 = kε0A/d
=> 6 x 8.85 x 10^-12 x 6 x 10^-3 / 3 x 10^-3
=> 108 x 10^-12 F = 108 pF
(iii) Q = CV
=> 108 x 10^-12 x 100/6
=> 1.8 x 10^-9 C
(b) if battery is connected then potential will be same but charge will increase
∴ V = 100 V
Q = 1.8 x 10^-9 x 6
=> 1.08 x 10^-8 C
but capacitance will be same
i.e. 108 pF
— : End Parallel Plate Capacitor Numerical for Class-12 Nootan ISC Physics Ch-4 Capacitors and Dielectrics :–
