The Plane Class 12 OP Malhotra Exe-24F Solutions

Que-1: Find the equation of the plane which
(i) passes through P(3, -2, 4) and is perpendicular to a line whose direction ratios are 2, 2, -3;
(ii) passes through P(2, -3, 5) and has the line joining A(1, -3, -5) and B(2, 2, 3) as a normal;
(iii) bisects the line joining (5, -2, 6) and (7, 2, 0) at right angles;
(iv) passes through P(1, -2, -4) and is parallel to the plane 7 x – 4 y + 6 z + 2 = 0;
(v) passes through the points (-8, 6, 0),(0, 12, 0), and (-10, 0, -9);
(vi) passes through the points (6, 2, 3),(3, 3, -2),(2, -2, -1);
(vii) passes through the y-axis and the point (4, 2, -3).

Sol: (i) Given direction ratios of normal to plane are ∴ < 2, 2, 3 >.
Thus, eqn. of plane through the point (3, -2, 4) and having direction ratios of normal to plane are
∴ < 2, 2, -3 > is given by 2(x – 3) + 2(y + 2) – 3(z – 4) = 0
⇒ 2 x + 2 y – 3 z + 10 = 0 be the required eqn. of plane.

(ii) ∴ directon ratios of normal to required plane are
∴< 2 – 1, 2 + 3, 3 + 5 >
i.e. ∴ < 1, 5, 8 > Thus required eqn. of plane through the point P(2, -3, 5) is given by
1(x – 2) + 5(y + 3) + 8(z – 5) = 0
⇒ x + 5 y + 8 z – 27 = 0

(iii) D ratios of line AB are
< 7 – 5, 2 + 2, 0 – 6 > i.e.
< 2, 4, -6 > Thus A B be normal to required plane. Also the required plane passes through the mid point of AB
i.e. 5+7/2, −2+2/2, 6+0/2 i.e. (6, 0, 3).
∴ eqn. of plane through the point (6, 0, 3) is given by
1(x – 6) + 2(y – 0) – 3(z – 3) = 0
⇒ x + 2 y – 3 z + 3 = 0

(iv) eqn. of plane parallel to given plane
7 x – 4 y + 6 z + 2 = 0 be given by 7 x – 4 y + 6 z + k = 0
Since eqn. (1) passes through the point P(1,-2,-4).
∴ 7 × 1 – 4 × (-2) + 6(-4) + k = 0
⇒ 7 + 8 – 24 + k = 0 ⇒ k = 9
putting the value of k in eqn. (1) ; we have
7 x – 4 y + 6 z + 9 = 0 be the reqd. eqn. of plane.

(v) Let the eqn. of plane through the point (-8, 6, 0) be given by
a(x + 8) + b(y – 6) + c(z – 0) = 0
Now eqn. (1) passes through the point (0, 12, 0).
∴ 8 a + 6 b + 0 c = 0
⇒ 4 a + 3 b + 0 c = 0
Also, plane (1) passes through the point (-10, 0, -9)
∴ a(-10 + 8) + b(0 – 6) + c(-9 – 0) = 0
⇒ -2 a – 6 b – 9 c = 0
on solving eqn. (2) and eqn. (3); we have
a−2/7−0 = b/0+36
= c/−24+6
⇒ a/−27
= b/36 = c/−18
⇒ a/3 = b/−4
= c/2 = k (say) where k ≠ 0
∴ a = 3 k ; b = -4 k and c = 2 k
putting the values of a, b and c in eqn. (1); we have
3 k(x + 8) – 4 k(y – 6) + 2 k(z) = 0
⇒ 3 x – 4 y + 2 z + 48 = 0

(vi) Let the eqn. of plane through the point (6, 2, 3) is given by
a(x – 6) + b(y – 2) + c(z – 3) = 0
where ∴ < a, b, c > are the direction rates of normal to plane (1). eqn. (1) passes through the point (3, 3, -2).
a(3 – 6) + b(3 – 2) + c(-2 – 3) = 0
⇒ -3 a + b – 5 c = 0
Also, plane (1) passes through the point (2, -2, -1).
a(2 – 6) + b(-2 – 2) + c(-1 – 3) = 0
a + b + c = 0
⇒ -4 a – 4 b – 4 c = 0
By cross-multiplication method; we have
a/1+5 = b/−5+3
= c/−3−1
⇒ a/6 = b/−2
= c/−4
⇒ a/3 = b/−1 = c−2 = k (say); k ≠ 0
∴ a = 3 k ; b = -k ; c = -2 k
putting the values of a, b and c in eqn. (1); we have
3 k(x – 6) – k(y – 2) – 2 k(z – 3) = 0
⇒ 3 x – y – 2 z – 10 = 0 be the required eqn. of plane

(vii) since y-axis be the line of intersection of x o y plane (i.e. z = 0 ) and y o z plane ( i.e. x = 0 ) is given by
z + k x = 0
Since plane (1) passes through the point (4, 2, -3)
∴ -3 + 4 k = 0
⇒ k = 3/4
∴ from (1); z + 3x/4 = 0
⇒ 3 x + 4 z = 0 be the reqd. plane.

Que-2: Find the equation of the plane
(i) parallel to the plane 4 x – 4 y + 7 z – 3 = 0 and distant 4 units from the point (4, 1, -2);
(ii) which passes through the point (3, -2, 4) and is perpendicular to each of the planes 7 x – 3 y + z – 5 = 0 and 4 x – y – z + 9 = 0.
(iii) perpendicular to each of the planes 3 x – y + z = 0 and x + 5 y + 3 z = 0 and is at a distance of √6 from the origin ;
(iv) through (2, 2, 2) and (0, -2, 0) and perpendicular to the plane x – 2 y + 3 z – 7 = 0.

Sol: (i) eqn. of given plane be
4 x – 4 y + 7 z – 3 = 0 …………………….. (1)
Thus eqn. of plane parallel to plane (1) be given by
4 x – 4 y + 7 z + k = 0 …………………….. (2)
also it is given that ⊥ distance of point (4, 1, -2) from given plane (2) = 4 units
|4×4−4×1+7×(−2)+k|/√4²+(−4)²+7² = 4
⇒ |16−4−14+k|/√16+16+49 = 4
⇒ |k−2|/9 = 4
⇒ |k – 2| = 36 ⇒ k – 2 = ± 36
⇒ k = ± 36 + 2
⇒ k = 38, – 34
putting the values of k in eqn. (2); we have
4 x – 4 y + 7 z + 38 = 0 and 4 x – 4 y + 7 z – 34 = 0 be the required eqns. of planes.

(ii) The equations of given planes are ;
7 x – 3 y + z – 5 = 0 …………………….. (1)
4 x – y – z + 9 = 0 …………………….. (2)
Thus the eqn. of plane through the point (3, -2, 4) is given by
a(x – 3) + b(y + 2) + c(z – 4) = 0 …………………….. (3)
where < a, b, c > are the direction ratios of normal to plane (3).
Since the required plane (3) is ⊥ to plane (1) and (2).
∴ 7 a – 3 b + c = 0 …………………….. (4)
4 a – b – c = 0 …………………….. (5)
on solving eqn. (4) and (5) simultaneously using cross multiplication method, we have
a/3+1 = b/4+7
= c/−7+12
i.e. a/4 = b/11 = c/5 = k (say)
⇒ a = 4 k ; b = 11 k and c = 5 k
putting the values of a, b, c in eqn. (3); we have
4 k(x – 3) + 11 k(y + 2) + 5 k(z – 4) = 0
⇒ 4 x + 11 y + 5 z – 10 = 0 be the reqd. plane.

(iii) Let the eqn. of required plane be
a x + b y + c z + d = 0 …………………….. (1)
where < a, b, c > be the direction ratios of normal to plane (1).
The eqns. of given planes are
3 x – y + z = 0 …………………….. (2)
x + 5 y + 3 z = 0 …………………….. (3)
and
hiven planes.
Since the plane (1) is ⊥ to both given planes.
∴ 3 a – b + c = 0 …………………….. (4)
a + 5 b + 3 c = 0 …………………….. (5)
on solving (4) and (5) simultaneously
∴ a/−8 = b/1−9 = c/15+1
⇒ a/1 = b/1
= c/−2 = k (say) ; where k ≠ 0
∴ a = k ; b = k ; c = -2 k
putting the values of a, b, c in eqn. (1); we have
x + y – 2 z + d/k = 0 …………………….. (6)
⇒ x + y – 2 z + d = 0
Also it is given that ⊥ distance from (0, 0, 0) to given plane (6) = √6
∣0+0−2×0+d′∣/√1²+1²+(−2)²
= √6
⇒ d = ± 6 .
∴ from eqn. (6); we have x + y – 2 z ± 6 = 0 be the reqd. equations of planes.

(iv) Let the eqn. of plane through the point (2, 2, 2) is given by
a(x – 2) + b(y – 2) + c(z – 2) = 0 …………………….. (1)
plane (1) passes through the point (0, -2, 0).
∴ a(0 – 2) + b(-2 – 2) + c(0 – 2) = 0
⇒ a + 2 b + c = 0 …………………….. (2)
⇒ -2 a – 4 b – 2 c = 0
Since eqn. (1) is ⊥ to plane
x – 2 y + 3 z – 7 = 0
a – 2 b + 3 c = 0 …………………….. (3)
a/6+2 = b/1−3
= c/−2−2
i.e. a/8 = b/−2 = c/−4
i.e. a/4 = b/−1 = c/−2 = k
∴ a = 4 k ; b = -k ; c = -2 k ; k ≠ 0
putting the values of a, b and c in eqn. (1); we have
4 k(x – 2) – k(y – 2) – 2 k(z – 2) = 0
⇒ 4 x – y – 2 z – 2 = 0 be the required eqn. of plane.

Que-3: Find the equation of the plane which contains the line of intersection of the planes x + 2 y + 3 z – 4 = 0 and 2 x + y – z + 5 = 0 and is perpendicular to the plane 5 x + 3 y – 6 z + 8 = 0.

Sol: Given eqns. of planes are ; and
x + 2 y + 3 z – 4 = 0 …………………….. (1)
2 x + y – z + 5 = 0 …………………….. (2)
Thus the eqn. of any plane through the line of intersection of given planes be
(x + 2 y + 3 z – 4) + k(2 x + y – z + 5) = 0
(1 + 2 k) x + (2 + k) y + (3 – k) z – 4 + 5 k = 0 …………………….. (3)
Now plane (3) is ⊥ to given plane
5 x + 3 y – 6 z + 8 = 0
∴ (1 + 2 k) 5 + ( 2 + k) 3 + (3 – k)(-6) = 0 …………………….. (4)
⇒ 5 + 10 k + 6 + 3 k – 18 + 6 k = 0
⇒ 19 k – 7 = 0
⇒ k = 7/19
putting the value of k = 719 in eqn. (3) ; we get
(1 + 14/19) x + (2 + 7/19) y + (3 – 7/19) z – 4 + 35/19 = 0
⇒ 33 x + 45 y + 50 z – 41 = 0 be the reqd. plane.

Que-4: Find the equation of the plane through the intersection of the planes x + y + z = 1 and 2 x + 3 y – z + 4 = 0 and parallel to the x-axis.

Sol: The eqn. of any palen through the line if intersection of two given planes x + y + z – 1 = 0 and 2 x + 3 y – z + 4 = 0 is given by
(x + y + z – 1) + k(2 x + 3 y – z + 4) = 0
⇒ (1 + 2 k) x + (1 + 3 k) y + (1 – k) z – 1 + 4 k = 0 …………………….. (1)
Now plane (1) is parallel to x-axis whose direction ratios are < 1, 0, 0 >
∴ Normal to plane (1) is ⊥ to x-axis.
Thus, (1 + 2 k) 1 + (1 + 3 k) 0 + (1 – k) 0 = 0
⇒ 2 k = -1
⇒ k = −1/2
∴ from (1); we have
−1/2 y + 3/2 z – 1 – 2 = 0
⇒ -y + 3 z – 6 = 0
⇒ y – 3 z + 6 = 0 be the required eqn. of plane.

Que-5: (i) Find the equation of the plane through (2, 3, -4) and (1, -1, 3) and parallel to the x-axis.
(ii) Find the equation of the plane passing through the points (2, 3, 1) and (4, -5, 3) and parallel to the x-axis.

Sol: (i) The eqn. of any plane through the point (2, 3, -4) is given by
a(x – 2) + b(y – 3) + c(z + 4) = 0 …………………….. (1)
where < a, b, c > are the direction ratios of normal to plane (1).
Also paine (1) passes through the point (1, -1, 3).
∴ a(1 – 2) + b(-1 – 3) + c(3 + 4) = 0
⇒ -a – 4 b + 7 c = 0 ⇒ a + 4 b – 7 c = 0 …………………….. (2)
Also plane (1) is parallel to x-axis.
∴ Normal to plane (1) is ⊥ to x-axis.
∴ a + 0 b + 0 c = 0 …………………….. (3)
on solving eqn. (2) and eqn. (3) simultaneously by cross-multiplication method, we have
a/0−0 = b/−7−0 = c/0−4
⇒ a/0 = b/−7 = c/−4 = k (say)
∴ a = 0 ; b = -7 k ; c = -4 k ; k ≠ 0
∴ from (1); we have
0(x – 2) – 7 k (y – 3) – 4 k(z + 4) = 0
⇒ -7 y + 21 – 4 z – 16 = 0
⇒ -7 y – 4 z + 5 = 0
⇒ 7 y + 4 z – 5 = 0 which is the required plane.

(ii) eqn. of any plane through the point (2, 3, 1) is given by
a(x – 2) + b(y – 3) + c(z – 1) = 0 …………………….. (1)
where < a, b, c > be the d ratios of normal to plane (1).
Now plane (1) passes through the point (4, -5, 3).
a(4 – 2) + b(-5 – 3) + c(3 – 1) = 0
⇒ 2 a – 8 b + 2 c = 0
⇒ a – 4 b + c = 0 …………………….. (2)
Since plane (1) is parallel to x-axis.
∴ Normal to plane (1) is ⊥ to x-axis whose direction ratios are < 1, 0, 0 > i.e. a + 0 b + 0 c = 0 …………………….. (3)
on solving eqn. (2) and eqn. (3) simultaneously
a/0 = b/1−0 = c/0+4 = k (say); k ≠ 0
⇒ a = 0 k = 0 ; b = k ; c = 4 k
putting the values of a, b and c in eqn. (1); we get
0(x – 2) + k(y – 3) + 4 k(z – 1) = 0
⇒ y + 4 z – 7 = 0
which is the required eqn. of plane.

Que-6: Find the equation of a plane which is perpendicular to the plane 2 x – 3 y + 6 z + 8 = 0 and passes through the intersection of the planes x + 2 y + 3 z – 4 = 0 and 2 x – y – z + 5 = 0.

Sol: eqns. of given planes are ;
x + 2 y + 3 z – 4 = 0 …………………….. (1)
2 x – y – z + 5 = 0  …………………….. (2)
and
Thus the eqn. of any plane through the line of intersection of given planes is given by
x + 2 y + 3 z – 4 + k(2 x – y – z + 5) = 0
⇒ (1 + 2 k) x + (2 – k) y + (3 – k) z – 4 + 5 k = 0 …………………….. (1)
Now plane (1) is normal to plane 2 x – 3 y + 6 z + 8 = 0
∴ 2(1 + 2 k) – 3(2 – k) + 6(3 – k) = 0
⇒ 2 + 4 k – 6 + 3 k + 18 – 6 k = 0
⇒ k + 14 = 0
⇒ k = -14
putting the value of k in eqn. (1); we have
-27 x + 16 y + 17 z – 74
⇒ 27 x – 16 y – 17 z + 74 = 0
⇒ 27, which is the reqd. plane.

Que-7: (i) Find the equation of the plane passing through A(-1, 1, 1) and B(1, 1, 1) and perpendicular to the plane x – 2 y + 2 z = 3.
(ii) Also, find the distance of the point A from the plane x – 2 y + 2 z = 3.

Sol: (i) Any plane through the point A(-1, 1, 1) be given by
a(x + 1) + b(y – 1) + c(z – 1) = 0 …………………….. (1)
where < a, b, c > are the direction ratios of normal to plane (1).
The point B(1, -1, 1) lies an eqn. (1); we have
a(1 + 1) + b(-1 – 1) + c(1 – 1) = 0
⇒ 2 a – 2 b + 0 c = 0
⇒ a – b + 0 c = 0 …………………….. (2)
Now plane (1) ⊥ to given plane
x – 2 y + 2 z = 3
a – 2 b + 2 c = 0 …………………….. (3)
∴ on solving eqn. (2) and eqn. (3) simultaneously by cross multiplication method, we have
a/−2−0 = b/0−2 = c/−2+1
i.e. a/−2 = b/−2 = c/−1
i.e. a/2 = b/2 = c/1 = k (say) ; k ≠ 0
∴ a = 2 k ; b = 2 k and c = k
putting the value of a, b and c in eqn. (1); we have
2 k(x + 1) + 2 k(y – 1) + k(z – 1) = 0
⇒ 2 x + 2 y + z – 1 = 0 be the reqd. plane

(ii) Required distance of A(-1, 1, 1) from x – 2 y + 2 z – 3 = 0
= |−1−2×1+2×1−3|/√1²+(−2)²+2²
= |−1−2+2−3|/3 = 4/3 units

Que-8: A plane meets the plane x = 0, where x = 0, 2 y – 3 z = 5, and the plane z = 0 where z = 0, 7 x + 4 y = 10. Find the equation to the plane.

Sol: The eqn. of any plane through the line of intersection of planes x = 0 and 2 y – 3 z – 5 = 0 be given by
2 y – 3 z – 5 + k x = 0 …………………….. (1)
Now plane (1) meets the planes z = 0 and 7 x + 4 y = 10
∴ from (1); 2 y – 5 + k (10−4y/7) = 0
i.e. 14 y – 35 + 10 k – 4 k y = 0
i.e. (14 – 4 k) y + 10 k – 35 = 0
∴ 14 – 4 k = 0 and 10 k – 35 = 0
i.e. k = 7/2 and k = 7/2
∴ from (1); 2 y – 3 z – 5 + 7/2 x = 0
⇒ 4 y – 6 z – 10 + 7 x = 0
which is the required eqn. of plane.

Que-9: Prove that the plane 2 x + y – 3 z + 5 = 0, 5 x – 7 y + 2 z + 3 = 0, 5 and x + 10 y – 11 z + 12 = 0 have a line in common.

Sol: The eqn. of plane through the line of intersection of first two planes is given by
2 x + y – 3 z + 5 + k(5 x – 7 y + 2 z + 3) = 0
⇒ (2 + 5 k) x + (1 – 7 k) y + (-3 + 2 k) z + 5 + 3 k = 0 …………………….. (1)
Now plane (1) is identical to given plane
if
x + 10 y – 11 z + 12 = 0
2−15k/1 = 1−7k/10
= −3−12k/−11 = 5+3k/12 …………………….. (2)
From first two fractions ; 20 + 50 k = 1 – 7 k
⇒ 57 k = -19 ⇒ k = −1/3
putting k = −1/3 in last two fractions ; we have
−3−(2/3)/−11 = 5−1/12
⇒ 1/3 = 1/3 which is true.
Thus the given three planes have same line of intersection.

Que-10: Find the equation of the plane passing through the intersection of the plane.
r→ (î + ĵ + k̂) = 1 and r→ (2î + 3ĵ – k̂) + 4 = 0 and parallel to x-axis.

Sol: The eqn. of plane passing through the line of intersection of given planes
r→ (î +ĵ + k̂) = 1 and r→ (2î + 3ĵ – k̂) + 4 = 0
be given by r→ (î + ĵ + k̂) – 1] + λ[r⃗ (2î + 3ĵ – k̂) + 4] = 0
⇒ r→ [(1 + 2λ)î + (1 + 3λ)ĵ + (1 – λ) k̂] + 4λ – 1 = 0 …………………….. (1)
Since eqn. (1) is parallel to x-axis.
∴ Normal to plane is ⊥ to x-axis.
∴(1 + 2 λ) 1 + (1 + 3λ) 0 + (1 – λ) 0 = 0
⇒ 1 + 2λ = 0
⇒ λ = −1/2
∴ from (1) ; we have
r⃗ [−ĵ/2 + 3/2 k̂] – 3 = 0

–: End of Angle Between Two Planes Class 12 OP Malhotra Exe-24E ISC Maths Solutions Ch-24 :–

Return to :- OP Malhotra ISC Class-12 S Chand Publication Maths Solutions
Please share with your friends
Thanks
